  2. 117 Series Temperature Switch (E117 )

117 Series Temperature Switch (E117 )

https://www.doger.com/web/image/product.template/10761/image_1920?unique=a6d0c34

Approved for Division 2, Zone 2 hazardous and corrosive atmospheres, and with optional Zone 0 intrinsic safety compliance, the 117 Series can be used to measure vacuum, pressure, differential pressure, or temperature in a variety of applications.

Type E117 - Bulb and capillary; One SPDT output; epoxy coated enclosure; internal adjustment with reference dial

  • Temperature parameters

This combination does not exist.

United Electric Controls
Pressure switches, temperature switches, thermocouples, RTDs, pressure and temperature transmitters, gas detection

The rugged, one piece enclosure features a slanted cover for wiring accessibility to the enclosed terminal block that is wired to either a SPDT or DPDT hermetically sealed microswitch. All welded, stainless steel pressure connections and sensors provide superior corrosion resistance – NACE compliant – and fire-safe protection within the harshest environments.

The 117 Series is an ideal choice for the most demanding applications; typically steel and aluminum mills, chemical and petrochemical plants, pulp and paper mills, wastewater treatment plants, midstream and downstream oil & gas, and pharmaceutical plants.

Parameters available in the datasheet of the documents section


Specifications for 117 Series Temperature Switch (E117 )

Temperature parameters 2BSA - Set Point Range: -120 to 100 °F /Max. Temp: 150 °F / Scale Division : 10 °F /Stem size : 3/8 x 2-5/8” or 5BS - Set Point Range: -20 to 80 °F /Max. Temp: 130°F / Scale Division : 5 °F /Stem size : 3/8 x 5” or 4BS - Set Point Range: 25 to 100 °F /Max. Temp: 150 °F / Scale Division : 2 °F /Stem size : 3/8 x 6-3 ⁄ 4” or 2BSB - Set Point Range: 30 to 250 °F /Max. Temp: 150 °F / Scale Division : 10 °F /Stem size : 3/8 x 2-5/8” or 3BS - Set Point Range: 100 to 400 °F /Max. Temp: 450 °F / Scale Division : 10 °F /Stem size : 3/8 x 2-1 ⁄ 8” or 8BS - Set Point Range: 350 to 640 °F /Max. Temp: 690 °F / Scale Division : 10 °F /Stem size : 3/8 x 2-5/8”
UEONLINE 117 Series Datasheet.pdf
Download
  • Approved for Division 2, Zone 2 hazardous locations
  • Optional ATEX or EAC intrinsic safety compliance for Zone 0
  •  Hermetically sealed snap switch, SPDT or DPDT output
  • Many models compliant to NACE MR0175
  • Optional sensor material for corrosive media
  • Ultra-low vacuum and pressure ranges
  • Polished stainless steel flush mount sensors
