117 Series Pressure Switch (H117 Models 701-706 )

https://www.doger.com/web/image/product.template/10756/image_1920?unique=8059cbe

Approved for Division 2, Zone 2 hazardous and corrosive atmospheres, and with optional Zone 0 intrinsic safety compliance, the 117 Series can be used to measure vacuum, pressure, differential pressure, or temperature in a variety of applications.

H117 - One SPDT output; epoxy coated enclosure; internal adjustment with “High-Low” reference scale.

Buna N diaphragm and O-ring with 316 stainless steel 1/4” NPT (female) pressure connection; option M540 VitonR diaphragm and O-ring available

  • Pressure parameters .

This combination does not exist.

United Electric Controls
Pressure switches, temperature switches, thermocouples, RTDs, pressure and temperature transmitters, gas detection

The rugged, one piece enclosure features a slanted cover for wiring accessibility to the enclosed terminal block that is wired to either a SPDT or DPDT hermetically sealed microswitch. All welded, stainless steel pressure connections and sensors provide superior corrosion resistance – NACE compliant – and fire-safe protection within the harshest environments.

The 117 Series is an ideal choice for the most demanding applications; typically steel and aluminum mills, chemical and petrochemical plants, pulp and paper mills, wastewater treatment plants, midstream and downstream oil & gas, and pharmaceutical plants.

Parameters available in the datasheet of the documents section


Specifications for 117 Series Pressure Switch (H117 Models 701-706 )

Pressure parameters . 700 - Set Point Range: 3 to 20 psi /Deadband: 1,0 to 4 psi /Over Range Pressure : 500 psi / Proof Pressure: 1000 psi or 702 - Set Point Range: 3 to 100 psi /Deadband: 2 to 12 psi /Over Range Pressure : 500 psi / Proof Pressure: 1000 psi or 704 - Set Point Range: 3 to 20 psi /Deadband: 15 to 500 psi /Over Range Pressure : 1500 psi / Proof Pressure: 2500 psi or 706 - Set Point Range: 100 to 1700 psi /Deadband: 20 to 110 psi /Over Range Pressure : 2000 psi / Proof Pressure: 2500 psi
UEONLINE 117 Series Datasheet.pdf
Download
  • Approved for Division 2, Zone 2 hazardous locations
  • Optional ATEX or EAC intrinsic safety compliance for Zone 0
  •  Hermetically sealed snap switch, SPDT or DPDT output
  • Many models compliant to NACE MR0175
  • Optional sensor material for corrosive media
  • Ultra-low vacuum and pressure ranges
  • Polished stainless steel flush mount sensors
