117 Series Pressure Switch (H117 Model 218)

https://www.doger.com/web/image/product.template/10752/image_1920?unique=7db9e02

Approved for Division 2, Zone 2 hazardous and corrosive atmospheres, and with optional Zone 0 intrinsic safety compliance, the 117 Series can be used to measure vacuum, pressure, differential pressure, or temperature in a variety of applications.

H117 - One SPDT output; epoxy coated enclosure; internal adjustment with “High-Low” reference scale.

218 - Set Point Range: 30 “Hg Vac to 0 psi /Deadband: 2 to 5 “Hg /Over Range Pressure : 3 psi / Proof Pressure: 30psi

    This combination does not exist.

    United Electric Controls
    Pressure switches, temperature switches, thermocouples, RTDs, pressure and temperature transmitters, gas detection

    The rugged, one piece enclosure features a slanted cover for wiring accessibility to the enclosed terminal block that is wired to either a SPDT or DPDT hermetically sealed microswitch. All welded, stainless steel pressure connections and sensors provide superior corrosion resistance – NACE compliant – and fire-safe protection within the harshest environments.

    The 117 Series is an ideal choice for the most demanding applications; typically steel and aluminum mills, chemical and petrochemical plants, pulp and paper mills, wastewater treatment plants, midstream and downstream oil & gas, and pharmaceutical plants.

    Phosphor bronze bellows with nickel-plated brass 1/4” NPT (female) pressure connection; 303 stainless steel spring exposed to media

    Parameters available in the datasheet of the documents section


    UEONLINE 117 Series Datasheet.pdf
    Download
    • Approved for Division 2, Zone 2 hazardous locations
    • Optional ATEX or EAC intrinsic safety compliance for Zone 0
    •  Hermetically sealed snap switch, SPDT or DPDT output
    • Many models compliant to NACE MR0175
    • Optional sensor material for corrosive media
    • Ultra-low vacuum and pressure ranges
    • Polished stainless steel flush mount sensors
