  2. 117 Series Temperature Switch (B117 Models 120-121 )

117 Series Temperature Switch (B117 Models 120-121 )

https://www.doger.com/web/image/product.template/10760/image_1920?unique=87d1129

Approved for Division 2, Zone 2 hazardous and corrosive atmospheres, and with optional Zone 0 intrinsic safety compliance, the 117 Series can be used to measure vacuum, pressure, differential pressure, or temperature in a variety of applications.

Type B117 - Immersion stem; One SPDT output; epoxy coated enclosure; internal adjustment with reference dial

  • Temperature parameters

Esta combinación no existe.

United Electric Controls
Interruptores de presion, interruptores de temperatura, Termocuplas, RTDs, transmisores de temperatura y presioón, detección de gases

The rugged, one piece enclosure features a slanted cover for wiring accessibility to the enclosed terminal block that is wired to either a SPDT or DPDT hermetically sealed microswitch. All welded, stainless steel pressure connections and sensors provide superior corrosion resistance – NACE compliant – and fire-safe protection within the harshest environments.

The 117 Series is an ideal choice for the most demanding applications; typically steel and aluminum mills, chemical and petrochemical plants, pulp and paper mills, wastewater treatment plants, midstream and downstream oil & gas, and pharmaceutical plants.

Parameters available in the datasheet of the documents section


Specifications for 117 Series Temperature Switch (B117 Models 120-121 )

Temperature parameters 120 - Set Point Range: 0 to 225 °F /Max. Temp: 275 °F / Scale Division : 10 °F /Stem size : 9/16” x 1-7⁄ 8” below 1/2” NPT thread (nickel-plated brass) or 121 - Set Point Range: 200 to 425 °F /Max. Temp: 475 °F / Scale Division : 10 °F /Stem size : 9/16” x 1-7⁄ 8” below 1/2” NPT thread (nickel-plated brass)
UEONLINE 117 Series Datasheet.pdf
Download
  • Approved for Division 2, Zone 2 hazardous locations
  • Optional ATEX or EAC intrinsic safety compliance for Zone 0
  •  Hermetically sealed snap switch, SPDT or DPDT output
  • Many models compliant to NACE MR0175
  • Optional sensor material for corrosive media
  • Ultra-low vacuum and pressure ranges
  • Polished stainless steel flush mount sensors


Product Image
117 Series Temperature Switch (B117 Models 120-121 )
