117 Series Differential Pressure Switch (H117K Models 540-548 )

https://www.doger.com/web/image/product.template/10757/image_1920?unique=4156fc5

Approved for Division 2, Zone 2 hazardous and corrosive atmospheres, and with optional Zone 0 intrinsic safety compliance, the 117 Series can be used to measure vacuum, pressure, differential pressure, or temperature in a variety of applications.

Type H117K - One SPDT output; epoxy coated enclosure; internal adjustment with “High-Low” reference scale

Buna N diaphragm and sealing diaphragms with epoxy coated aluminum 1/8” NPT (female) pressure connections.

  • Differential Pressure parameters

Esta combinación no existe.

United Electric Controls
Interruptores de presion, interruptores de temperatura, Termocuplas, RTDs, transmisores de temperatura y presioón, detección de gases

The rugged, one piece enclosure features a slanted cover for wiring accessibility to the enclosed terminal block that is wired to either a SPDT or DPDT hermetically sealed microswitch. All welded, stainless steel pressure connections and sensors provide superior corrosion resistance – NACE compliant – and fire-safe protection within the harshest environments.

The 117 Series is an ideal choice for the most demanding applications; typically steel and aluminum mills, chemical and petrochemical plants, pulp and paper mills, wastewater treatment plants, midstream and downstream oil & gas, and pharmaceutical plants.

Parameters available in the datasheet of the documents section


Specifications for 117 Series Differential Pressure Switch (H117K Models 540-548 )

Differential Pressure parameters 540 - Set Point Range: 0.8 to 7 “wcd /Deadband: 0.1 to 1.3 “wc /Working Pressure : 30 “Hg to 200 psi / Proof Pressure: 400 psi or 541 - Set Point Range: 2 to 20 “wcd /Deadband: 0.2 to 1.6 “wc /Working Pressure : 30 “Hg to 200 psi / Proof Pressure: 400 psi or 542 - Set Point Range: 5 to 50 “wcd /Deadband: 0.4 to 4.0 “wc /Working Pressure : 30 “Hg to 200 psi / Proof Pressure: 400 psi or 543 - Set Point Range: 10 to 200 “wcd /Deadband: 0.8 to 12 “wc /Working Pressure : 30 “Hg to 200 psi / Proof Pressure: 400 psi or 544 - Set Point Range: 2 to 20 psid /Deadband: 0.2 to 2 psid /Working Pressure : 30 “Hg to 1200 psi / Proof Pressure: 2500 psi or 545 - Set Point Range: 5 to 50 psid /Deadband: 0.4 to 3.2 psid /Working Pressure : 30 “Hg to 1200 psi / Proof Pressure: 2500 psi or 546 - Set Point Range: 10 to 125 psid /Deadband: 0.7 to 7 psid /Working Pressure : 30 “Hg to 1200 psi / Proof Pressure: 2500 psi or 547 - Set Point Range: 50 to 250 psid /Deadband1 to 15 psid /Working Pressure : 30 “Hg to 1200 psi / Proof Pressure: 2500 psi or 548 - Set Point Range: 100 to 500 psid /Deadband: 2 to 20 psid /Working Pressure : 30 “Hg to 1200 psi / Proof Pressure: 2500 psi
UEONLINE 117 Series Datasheet.pdf
Download
  • Approved for Division 2, Zone 2 hazardous locations
  • Optional ATEX or EAC intrinsic safety compliance for Zone 0
  •  Hermetically sealed snap switch, SPDT or DPDT output
  • Many models compliant to NACE MR0175
  • Optional sensor material for corrosive media
  • Ultra-low vacuum and pressure ranges
  • Polished stainless steel flush mount sensors
