  2. 100 Series Temperature Switch Type B100 - Local immersion stem

100 Series Temperature Switch Type B100 - Local immersion stem

https://www.doger.com/web/image/product.template/10739/image_1920?unique=b200f02

The 100 Series is simple to install and operate for alarm, safety and emergency shutdown applications where preserving process uptime, and protecting personnel and equipment are paramount.

Type B100 - Immersion stem; one SPDT output; internal adjustment with reference dial

Note:
To view optional products click ADD TO CAR.

  • Temperature parameters

Esta combinación no existe.

United Electric Controls
Interruptores de presion, interruptores de temperatura, Termocuplas, RTDs, transmisores de temperatura y presioón, detección de gases

A rugged switch, the 100 Series is ideal for both heavy industry and the OEM, and carries global agency certification. As an electromechanical switch, it can safely operate independently of the control system and switch reliably when called upon, free from potential communication errors or cyber concerns.
Typical applications that utilize the 100 Series include controlling rotating equipment – pumps, turbines, and compressors, heat tracing, fire suppression systems, and fuel/gas trains.

Parameters available in the datasheet of the documents section

Specifications for 100 Series Temperature Switch Type B100 - Local immersion stem

Temperature parameters 120 - Set Point Range: 0 to 225 °F /Max. Temp: 275 °F / Scale Division : 10 °F /Stem size : 9/16" x 1-7/8" below 1/2" NPT or 121 - Set Point Range: 200 to 425 °F /Max. Temp: 475 °F / Scale Division : 10 °F /Stem size : 9/16" x 1-7/8" below 1/2" NPT
UEONLINE 100 Series Datasheet.pdf
Download
  • SIL 2 certified (SIL 3 capable) switch providing reliable local switching of final elements in safety instrumented systems (SIS)
  • Quick and easy installation with ample access to wiring compartment and simple set point adjustment using reference dial or scale, and calibrated gauge
  • Application versatility achieved through a variety of ranges, microswitches, sensors and process connections
  • Protect piping and vessels with heat trace/freeze protection temperature models


Product Image
100 Series Temperature Switch Type B100 - Local immersion stem
